Hard Disk Drive Packaging Pouches Aluminium ESD Bag
Metalized Shielding Pouches Faraday Bags
| NO | Item | Unit | Test standard and result |
| 1 | Metal layer resistance | Ohm/sq | <0.1 |
| 2 | Water VaporTransmission | Optical density | 0.0006gm/100sq.in./24hrs |
| 3 | Surface resistivity | Ohm/sq | 108-1011 |
| 4 | Time for static removal | 5000-0V | <0.01 sec FTMS 101 B Method 4046 |
| 5 | Puncture resistance | P.S.I | ASTM D3420 >100 |
| 6 | MVTR | gm/100in-2/24hrs | ASTM E 96 <0.2 |
| 7 | Oxygen Barrier | CC/100in-2/24hrs | ASTM D 3985 <0.5 |
| 8 | Hot sealing temperature | F | 250-375F |
| 9 | Seal strength | N/15mm | 25.2 |
Moisture Barrier Bag Esd Metalized Shielding Pouches Faraday Bags
Specifications
1.superior barrier of moisture, light;
2.superior puncture resistance;
3.with certificates such as Rohs
5P-- Protective;
Printing welcome;
Puncture resistance;
Polyethylene or polypropylene made;
Promotion function if printed with character, image and trademark.
| Material and weight ratio | PET12 11.8%, PE135 87.0%, PU 1.3% |
| Thickness | 0.149mm+0.007mm |
| Facade | Silver, no wrinkle, no perforation, on serious creases, small crystal |
| Surface resistivity | less than 10^11 Ohm, normal 10^9-10^10 Ohm |
| Electrostatic shielding voltage | less than 30V |
Anti-static.
This kind of bag can keep products away from damages due to static, Its special four -layer structure can create such effect as an inductive cover to separate the goods inside from the static field
Strong Sealing.
*High quality bone strips edge sealing
*Unique concave and convex button technology
*Resealable Zipper
Anti-static Bags.
*APET/CPP material,Premium Quality
*Dual Anti-static Coating,
*Durableine.
Semi-transparent and Environmentally Friendly.
*Goods inside can be easily recognized from outside
*Dust and moisture
Application
For electronics
Can store a variety of items, such as hard disks, RAMs,processor, I/O Cards, ETC.
Anti-static for precision parts.
APET/CPP material,Premium Quality
Protect all kinds of precision parts
For Office supplies.
Receive invoice,certificate,documents.
Daily necessities
Sensitive electronic components.
Effectively prevent harm to precise equipment and parts caused by static electricity.
ES19101 Printed Anti-static LDPE Foil ESD Anti Static Shielding Antistatic Plastic Zip Lock Packing Moisture Barrier Mbb Vacuum Bag
It is suitable for packing of PCB, IC and other static sensitive components.
The kind of bag can keep static-sensitive components away from the potential static danger to the largest extent.
Its special four -layer structure can create such effect as an inductive cover to separate the goods inside from the static field.
The inner layer is made from ethane which can remove the static and avoid static generation inside the bag.
This kind of hot seal bag is transparent, so the goods inside can be easily recognized from outside. The surface resistance: 10e8~10e11Ω
And physical property meet the ASTMD257, ELA541 and MIL-B-81705 international standards
*Material: 3-layer compound structure
*Static shielding: <30V
*Static discharging time: <0.03S
*Surface resistance: 10^9~10^11 Ohm
*Suitable for PCB,IC and other static sensitive components packing
*Feature: half transparent design in easy to check the item inside
*Standard: ASTMD257,ELA541,MIL-B1705
*Different sizes available
